The HVE-016-F is a high-voltage heavy-duty electrical connector designed for safe power transmission in renewable energy inverters, high-voltage test benches, and industrial power distribution systems. Constructed with a lightweight aluminum alloy housing and tin-plated copper contacts, it offers excellent resistance to high-voltage arcing, chemical corrosion, and UV radiation, making it suitable for both indoor and outdoor harsh operating environments.
Rated for 16A current and 2500V AC/DC, this connector ensures low-loss, stable power transfer for medium-load high-voltage applications, supporting flexible cable-mount configurations. It operates reliably across a wide temperature range of -40°C to 125°C and holds an IP66 ingress protection rating, guarding against dust accumulation and high-pressure water jets.
Equipped with a secure bayonet locking mechanism, the HVE-016-F prevents accidental disconnection during operation and ensures safe mating/unmating procedures. Fully compliant with IEC 61984 and RoHS standards, it meets strict global safety and environmental requirements, serving as a dependable solution for high-voltage industrial connectivity needs.

Technical Data
| Series | HVE insert series |
| Connection Type | Screw connection |
| Gender | Female |
| Specifications | 24B |
| Number of Connector Contacts | 16+2 (two contacts for high voltage safety) |
| Grounding Contacts | Yes |
| Rated Current | 16A |
| Rated Voltage | 400V |
| Rated Pulse Voltage | 6KV |
| Pollution Degree | 3 |
| Rated Voltage (UL/CSA) | 600V |
| Insulation Resistance | ≥10¹⁰Ω |
| Working Temperature | -40℃...+125℃ |
| Mating Cycles | ≥500 |
| Insert Material | Polycarbonate |
| Insert Color | RAL 7032 (light gray) |
| Flame Retardant Rating (UL94) | V0 |
| Contact Material | Copper alloy |
| Surface Treatment | Silver-plated |
| Contact Resistance | ≤1mΩ |
| Wire Gauge (mm²) | 0.75-2.5mm² |
| Wire Gauge (AWG) | 18-14 AWG |
| Tightening/Testing Torque | 0.5Nm |
| Stripping Length | 7mm |
| Standards | DIN EN 60 664, DIN EN 61984 |
