The HVE-006-F(7-12) is a high-voltage heavy-duty connector optimized for stable power transmission in new energy vehicle auxiliary power systems, industrial high-voltage control sub-units, and battery pack sampling modules. It features a corrosion-resistant aluminum alloy housing and silver-plated copper alloy contacts, delivering excellent resistance to electrical arcing, thermal cycling, and chemical corrosion, ideal for harsh industrial pollution grade 3 environments.
Rated for an adjustable 7–12A current and 830V AC/DC, it withstands an 8kV rated impulse voltage to handle sudden high-voltage surges and transient overvoltage. Adopting screw crimping termination, it is compatible with 0.75–2.5mm² wires, with contact resistance ≤1mΩ and insulation resistance ≥10¹⁰Ω for low-loss, safe power transmission.
Operating reliably from -40°C to 125°C, it meets UL94 V-0 flame retardant standards and supports over 500 mating cycles. Fully compliant with IEC 60664-1 and IEC 61984, it fits 16B IP65 protective housings, making it a dependable solution for medium-power high-voltage scenarios with variable current requirements.
Technical Data
| Series | HVE insert series |
| Connection Type | Screw connection |
| Gender | Female |
| Specifications | 16B, 32B |
| Number of Connector Contacts | 6+2 (2 contacts for high-voltage safety) |
| Grounding Contacts | Yes |
| Rated Current | 16A |
| Rated Voltage | 830V |
| Rated Impulse Voltage | 8KV |
| Pollution Degree | Class 3 |
| Parameters at Pollution Degree 2 | 16A 1000V 8KV 2; 16A 720/1250V 8KV 2 |
| Rated Voltage (UL/CSA) | 600V |
| Insulation Resistance | ≥10¹⁰Ω |
| Operating Temperature | -40℃...+125℃ |
| Mating Cycles | ≥500 cycles |
| Insert Material | Polycarbonate |
| Insert Color | RAL 7032 (Light Gray) |
| Flame Retardant Rating (UL94) | V0 |
| Contact Material | Copper Alloy |
| Surface Treatment | Silver-Plated |
| Contact Resistance | ≤1mΩ |
| Wire Gauge (mm²) | 0.75-2.5mm² |
| Wire Gauge (AWG) | 18-14 AWG |
| Tightening/Testing Torque | 0.5Nm |
| Stripping Length | 7mm |
| Standards | DIN EN 60 664, DIN EN 61984 |
