HMPE.M-001.2-M is a high-performance engineering component forged from premium High-Modulus Polyethylene (HMPE), engineered for rugged reliability in demanding industrial settings. It offers exceptional tensile strength, superior chemical resistance, and low friction, ensuring consistent performance in harsh environments prone to wear, corrosion, or extreme temperatures. As an upgraded mid-range variant, it features enhanced dimensional precision and optimized load-bearing capacity, enabling seamless compatibility with existing systems. Ideal for machinery, aerospace, marine, and industrial automation applications, it delivers stable operation while minimizing maintenance efforts and costs. Compliant with stringent industry quality standards, this component balances robust construction with lightweight design, making it a dependable choice for critical operations requiring long-term durability, efficiency, and adaptability to diverse working conditions.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Axial bolt connection |
| Male/female | Male |
| Number of connector contacts | 1 |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Zinc alloy |
| Insert surface treatment | Nickel-plated |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤0.3mΩ |
| Wire gauge (mm²) | 16-35mm² |
| Tightening/testing torque | 16mm²→6Nm25mm²→7Nm35mm²→8Nm |
| Stripping length | 13mm |
| Standard | DIN EN 60 664DIN EN 61 984 |
