HMPE.M-001.1-M is a high-performance engineering component crafted from premium High-Modulus Polyethylene (HMPE), designed for reliable performance in demanding industrial environments. It boasts excellent tensile strength, outstanding chemical resistance, and low-friction properties, ensuring stable operation in harsh conditions involving wear, corrosion, or extreme temperatures. As a basic mid-range model, it features precisely calibrated dimensional accuracy and load-bearing capacity optimized for mainstream application needs, enabling seamless integration with existing systems. Suitable for machinery manufacturing, aerospace, marine engineering, and related fields, it delivers consistent performance while effectively reducing maintenance frequency and costs. Compliant with industry quality standards, it achieves a balance of high strength and light weight, making it a trusted choice for critical operations requiring long-term stability and efficiency.

Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Axial bolt connection |
| Male/female | Male |
| Number of connector contacts | 1 |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Zinc alloy |
| Insert surface treatment | Nickel-plated |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤0.3mΩ |
| Wire gauge (mm²) | 10-25mm² |
| Tightening/testing torque | 10mm²→6Nm16mm²→6Nm25mm²→7Nm |
| Stripping length | 13mm |
| Standard | DIN EN 60 664DIN EN 61 984 |
