The HMK-003-FC-V2 is a high-performance industrial connector perfectly compatible with its counterpart HMK-003-MC-V2, forming a reliable mating pair for critical connectivity. Boasting IP67 dustproof/waterproof protection, it endures extreme temperatures (-40°C to +125°C), vibration, and corrosion, ensuring durability in harsh environments.
Its FC interface delivers enhanced connection stability with precise alignment, supporting 3 precision contacts rated for 16A/500V AC/DC for low-interference signal transmission and efficient power distribution. Crafted from corrosion-resistant, flame-retardant materials, it meets UL, IEC, and RoHS standards. The tool-free quick-locking mechanism enables easy installation.
Ideal for compact industrial automation, robotics, and renewable energy systems, it excels in space-constrained, high-reliability scenarios.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 3 |
| Rated current | 40A |
| Rated voltage | 690V |
| Rated pulse voltage | 8KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 1.5-6mm² |
| Wire gauge (AWG) | 16-10 AWG |
| Maximum cable diameter | 8mm |
| Stripping length | 9.6-12mm |
| Standard | DIN EN 60664, DIN EN 61984 |
