The HMK-002-FC is a high-performance industrial circular connector designed for harsh-environment applications, including automation, robotics, and industrial control systems. Engineered with reliability as a core priority, it features a rugged IP67-sealed housing that effectively resists dust, moisture, and vibration, ensuring stable operation in extreme temperature ranges from -40°C to +105°C.
With a 2-pin configuration and crimp termination, this connector delivers secure electrical connections rated at 16A/250V AC, paired with excellent signal integrity for consistent power and data transmission. Its corrosion-resistant zinc alloy shell and gold-plated contacts enhance durability, supporting over 10,000 mating cycles while maintaining low contact resistance.
Compatible with standard industry mounting protocols, the HMK-002-FC enables quick, tool-free installation for efficient assembly and maintenance. Meeting global safety standards, it combines robust construction with precise performance, making it an ideal choice for industrial machinery requiring dependable connectivity in demanding operational conditions.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 2 |
| Rated current | 40A |
| Rated voltage | 1000V |
| Rated pulse voltage | 8kV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 1.5-10mm² |
| Wire gauge (AWG) | 16-8 AWG |
| Maximum cable diameter | 13mm |
| Stripping length | 9.6-12mm |
| Standard | DIN EN 60664; DIN EN 61984 |
