HMK-002.1-F (2.5-8mm2) | High-Quality Rectangular Connectors

The HMK-002.1-F is a high-performance industrial connector engineered for cables with a cross-sectional area of 2.5-8mm², ideal for demanding electrical connection scenarios. It features a robust current-carrying capacity and reliable signal transmission, ensuring stable performance even in harsh operating conditions.

Crafted from premium flame-retardant PC housing and corrosion-resistant copper alloy contacts, the connector offers excellent durability, chemical resistance, and mechanical strength. Its precision-engineered design enables secure, vibration-proof mating, preventing accidental disconnection and extending service life.

Suitable for industrial automation, power distribution systems, renewable energy equipment, and heavy-duty machinery, this connector meets international safety standards for electrical installations. It provides a cost-effective, low-maintenance solution for critical connections requiring both performance and longevity.

HMK-002.1-F (2.5-8mm2) | High-Quality Rectangular Connectors-RedTech360

Technical Data

Series	HM modular insert series
Module size	Single module
Connection type	Axial bolt connection
Male/female	Female
Number of connector contacts	2
Rated current	40A
Rated voltage	1000V
Rated pulse voltage	8KV
Class of pollution	3
Insulation resistance	≥10¹⁰Ω
Working temperature	-40℃...+125℃
Mating cycles	≥500
Inserts material	Polycarbonate
Inserts color	RAL 7032 (light gray)
Flame retardant rating as per UL94	V0
Contact material	Copper alloy
Surface treatment	Silver-plated
Contact resistance	1mΩ
Wire gauge (mm²)	2.5-8mm²
Tightening/testing torque	2.5mm²→1.5Nm4mm²→1.5Nm6mm²→2Nm
Stripping length	2.5mm²→5⁺¹mm4mm²→5⁺¹mm6mm²→8⁺¹mm
Standard	DIN EN 60664DIN EN 61984
