The HMGB-008-MC is a high-performance industrial connector designed for reliable power and signal transmission in harsh operating environments. Boasting a rugged, corrosion-resistant housing and precision-engineered contacts, it ensures stable connectivity with low insertion loss and exceptional anti-vibration performance, meeting the stringent demands of industrial-grade applications.
Compliant with IP67 waterproof and dustproof standards, this connector is ideally suited for industrial automation, robotics, renewable energy systems, and heavy-duty machinery. Its wide operating temperature range of -40°C to +125°C enables consistent performance in extreme thermal conditions, while compatibility with multiple wire gauges enhances versatility across different installation requirements.
Equipped with a quick-locking mechanism, the HMGB-008-MC supports tool-free installation, significantly reducing assembly time and maintenance costs. Combining durability, user-friendly design, and superior electrical performance, it serves as a dependable solution for critical industrial connections that require long-term reliability and consistent performance.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Crimp connection |
| Male/female | Male |
| Number of connector contacts | 8+shield |
| Rated current | 5A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Zinc alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤4mΩ |
| Wire gauge (mm²) | 0.09-0.52mm² |
| Wire gauge (AWG) | 26-20 AWG |
| Bayonet range | 5-12 mm |
| Standard | DIN EN 60664, DIN EN 61984 |
