HMDS/2.1-009-FC is a high-performance hydrophobic coating agent designed to form a durable, ultra-thin protective layer on various substrates. Its core function lies in enhancing surface water repellency and corrosion resistance while maintaining the substrate’s original physical properties.
Ideal for electronics, optical components, and precision mechanical parts, it effectively shields surfaces from moisture, dust, and chemical erosion in harsh environments like high humidity or industrial workshops. Compared to conventional coatings, it offers faster curing speed, excellent adhesion, and long-lasting performance without compromising surface smoothness.
Easy to apply via spraying or dipping, it ensures uniform coverage and consistent quality, making it a reliable choice for both mass production and small-batch processing.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 9 |
| Rated current | 5A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated, Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.09-0.82mm² |
| Wire gauge (AWG) | 28-18 AWG |
| Maximum cable diameter | 2.5mm |
| Stripping length | 5mm |
| Standard | DIN EN 60664, DIN EN 61984 |
