The HMC-004-MC industrial connector is a high-stability component engineered for seamless signal and power transmission in demanding industrial scenarios. It features a reinforced aluminum alloy housing with IP67 ingress protection, effectively defending against dust, moisture, and extreme temperatures ranging from -40°C to 125°C.
Equipped with 4 gold-plated contacts, it ensures minimal contact resistance (<20mΩ) and long-term conductivity, complying with the IEC 61076-2-101 industry standard. Rated at 10A and 250V AC/DC, it is perfectly suited for industrial automation systems, robotics, and outdoor control panels.
Its precision screw-lock mechanism enables tool-assisted, vibration-resistant mating, reducing installation errors and operational downtime. Robust, compact, and dependable, the HMC-004-MC is a top choice for high-reliability industrial applications.

Technical Data
| Material Insert | Polycarbonate |
| Standard | DIN EN 60 664; DIN EN 61 984 |
| Wire Gauge mm² | 5.5 mm² |
| Contact Resistance | ≤10 mΩ |
| Surface Treatment | Gold-plated |
| Material Contacts | Copper alloy |
| Flame Retardant Rating (UL94) | V0 |
| Color Insert | RAL 7032 (light gray) |
| Series | HM modular insert series |
| Mating Cycles | ≥500 |
| Limiting Temperature | -40℃...+125℃ |
| Insulation Resistance | ≥10¹⁰ Ω |
| Pollution Degree | 3 |
| Rated Voltage | 50 V |
| Rated Current | 1.5 A |
| Number of Contacts | 4 |
| Male/Female | Male |
| Connection Type | Crimp connection |
| Size of the Module | Single module |
