The HM-RJ45-M is a rugged industrial-grade male RJ45 connector engineered for high-speed, reliable data transmission in harsh environments such as factory automation, industrial Ethernet networks, and surveillance systems. Featuring an IP67-sealed housing, it provides robust protection against dust, water ingress, and mechanical vibration, ensuring stable performance across extreme temperatures (-40°C to +85°C).
Compliant with TIA/EIA-568 standards, this connector supports Gigabit Ethernet (10/100/1000 Mbps) with exceptional signal integrity. Its gold-plated contacts minimize insertion loss and crosstalk, while the corrosion-resistant metal shell enhances durability, enabling reliable operation through 5,000+ mating cycles for long-term, low-maintenance connectivity.
Designed for seamless integration, the HM-RJ45-M offers standard RJ45 interface compatibility and tool-free installation, simplifying deployment and maintenance in industrial settings. Meeting global electromagnetic compatibility (EMC) and safety standards, it delivers consistent, high-performance data communication, making it the preferred choice for critical industrial applications requiring dependable network connectivity.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | - (Not specified) |
| Male/female | Male |
| Number of connector contacts | 8 |
| Rated current | 1A |
| Rated voltage | 50V; ＜30V (as per UL) |
| Rated pulse voltage | 0.8KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | - (Not specified) |
| Surface treatment | - (Not specified) |
| Contact resistance | - (Not specified) |
| Wire gauge (mm²) | - (Not specified) |
| Wire gauge (AWG) | - (Not specified) |
| Maximum cable diameter | - (Not specified) |
| Stripping length | - (Not specified) |
| Transmission Rate | 10/100/1000Mbit/10Gbit/s |
| Transmission Characteristics | Category 6e patch cords up to 500 MHz (as per ISO/IEC 24 702; ISO/IEC 11 801) |
| Standard | DIN EN 60664; DIN EN 61984 |
