The HEE-032-MC is a high-power medium-duty electrical connector designed for industrial automation, power distribution units, and renewable energy systems. Built with a rugged metal-clad housing and high-conductivity copper contacts, it provides exceptional resistance to vibration, thermal shock, and chemical exposure, ideal for harsh industrial environments.
Rated for 32A current and 450V AC/DC, this connector ensures low-resistance, stable power transmission for heavy-load applications. It supports cable-to-panel and wire-to-board configurations, with an operating temperature range of -50°C to 130°C and an IP66 rating that defends against dust ingress and high-pressure water jets.
Equipped with a twist-lock fastening system, the HEE-032-MC enables tool-free, secure mating that prevents accidental disengagement. Fully compliant with RoHS and IEC 61984 standards, it meets global safety and environmental regulations, serving as a reliable solution for high-current connectivity needs.
Technical Data
| Series | HEE insert series |
| Connection type | Crimp connection |
| Male/female | Male |
| Specifications | 16B；32B |
| Number of connector contacts | 32 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 830V 8KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated; Gold-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-4.0mm² |
| Wire gauge (AWG) | 26-12 AWG |
| Stripping length | 7.5mm |
| Standard | DIN EN 60 664；DIN EN 61984 |
