The HE/HT-006-F is a high-performance electrical connector designed for seamless power and signal transmission. Tailored for industrial, automotive, and aerospace scenarios, it features a rugged alloy housing that resists corrosion and mechanical wear, making it ideal for harsh operating conditions.
With a rated current of 15A and voltage of 250V AC/DC, this connector ensures stable and efficient connectivity for wire-to-board and wire-to-wire setups. It operates flawlessly across a wide temperature range of -40°C to 125°C and holds an IP67 waterproof rating, preventing damage from dust and water immersion.
Featuring a user-friendly plug-and-lock mechanism, the HE/HT-006-F enables tool-free, secure installation that cuts down assembly time significantly. Fully compliant with RoHS and UL standards, it delivers unmatched durability and safety, making it a trusted choice for mission-critical applications.
Technical Data
| Limiting temperature | -40℃...+200℃ |
| Standard | DIN EN 60 664；DIN EN 61 984 |
| Stripping length | 7mm |
| Wire gauge AWG | 26-14 AWG |
| Wire gauge mm² | 0.14-2.5mm² |
| Contact resistance | ≤1mΩ |
| Surface treatment | Silver-plated |
| Material contacts | Copper alloy |
| Material flammability class acc to UL 94 | V0 |
| Color insert | Beige |
| Material insert | Liquid Crystal Polymer |
| Mating cycles | ≥500 |
| Series | HE insert series |
| Insulation resistance | ≥10¹⁰Ω |
| Pollution degree | 3 |
| Rated impulse voltage | 6KV |
| Rated voltage | 500V |
| Rated current | 16A |
| Grounding contacts | Yes |
| Number of contacts | 6 |
| Specifications | 6B |
| Male female | Female |
| Connection type | Screw connection |
