The HE-016-MS B(17-32) is a heavy-duty male industrial circular connector engineered for high-reliability power and signal transmission in rugged industrial environments. Built with a durable metal housing and rated IP67 for ingress protection, it effectively resists dust, water immersion, and mechanical shock, ensuring consistent operation even in harsh outdoor or factory settings.
It comes with 16 gold-plated male contacts that minimize contact resistance and deliver stable connectivity. The connector supports a rated current of 7A per contact and a rated voltage of 350V AC/DC, with a broad operating temperature range from -40°C to 125°C to adapt to extreme thermal fluctuations.
Featuring a B-type bayonet locking mechanism, it enables tool-free, quick mating and unmating while providing vibration-resistant connections. Its 17–32 wire gauge compatibility makes it ideal for industrial automation lines, power distribution units, and heavy-duty machinery that demand secure, long-lasting multi-channel connectivity.
Technical Data
| Series | HE insert series |
| Connection type | Spring connection |
| Male/female | Male |
| Specifications | 16B、32B |
| Number of connector contacts | 16 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 400/690V 6KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Stripping length | 7-9mm |
| Standard | DIN EN 60 664, DIN EN 61984 |
