HE-016-MS B | High-Quality Rectangular Connectors

The HE-016-MS B is a heavy-duty male industrial circular connector, engineered for seamless and secure mating with female counterparts like the HE-016-FS B in harsh industrial scenarios. Its rugged metal housing features an IP67 ingress protection rating, offering robust defense against dust, moisture, and mechanical impact to ensure consistent performance in factory floors, outdoor installations, and heavy machinery setups.

Equipped with 16 gold-plated male contacts, the connector minimizes contact resistance and delivers stable power and signal transmission. It supports a rated current of 7A per contact and a rated voltage of 350V AC/DC, with a broad operating temperature range from -40°C to 125°C that adapts to extreme thermal fluctuations.

Featuring a B-type bayonet locking mechanism, it enables tool-free, quick mating and unmating while maintaining a vibration-resistant connection. This design makes it ideal for industrial automation systems, power distribution units, and heavy-duty equipment that demand durable, long-lasting multi-channel connectivity solutions.

Technical Data
