The HE-010-FS B is a heavy-duty female industrial circular connector, specially designed for secure mating with male connectors like the HE-010-MS B in rugged industrial settings. Its robust metal housing features an IP67 ingress protection rating, providing strong defense against dust, moisture, and mechanical shock to ensure consistent performance in harsh factory or outdoor environments.
Equipped with 10 gold-plated female contacts, the connector delivers low contact resistance and stable power transmission. It supports a rated current of 10A per contact and a rated voltage of 500V AC/DC, with a wide operating temperature range from -40°C to 125°C that adapts to extreme thermal fluctuations.
Featuring a B-type bayonet locking mechanism, it enables tool-free, quick mating and unmating while maintaining a vibration-resistant connection. This design makes it ideal for industrial automation systems, robotics, and heavy machinery that demand durable, long-lasting connectivity solutions.

Technical Data
| Series | HE insert series |
| Connection type | Spring connection |
| Male/female | Female |
| Specifications | 10B |
| Number of connector contacts | 10 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 400/690V 6KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Stripping length | 7-9mm |
| Standard | DIN EN 60 664, DIN EN 61984 |
