The HE-006-MSS is a robust industrial circular connector optimized for stable power and signal transfer in demanding operational settings. Equipped with 6 gold-plated contacts, it ensures minimal contact resistance and strong anti-corrosion performance, with a rated current of 10A per contact and a rated voltage of 400V AC/DC.
Featuring an IP67 waterproof and dustproof enclosure, it operates flawlessly in temperatures spanning from -40°C to +125°C, resisting shock and vibration via its durable metal shell. It is fully compatible with standard HE-series mating connectors and adopts a convenient bayonet quick-locking structure for rapid, firm assembly, making it a top choice for automation systems, robotics, and heavy industrial machinery.

Technical Data
| Series | HE insert series |
| Connection type | Spring connection |
| Male/female | Male |
| Specifications | 6B |
| Number of connector contacts | 6 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 400/690V 6KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Stripping length | 7-9mm |
| Standard | DIN EN 60 664、DIN EN 61984 |
