The HE-006-MQ P is a high-performance industrial circular connector engineered for reliable power and signal transmission in harsh operating environments. Boasting a compact, rugged metal housing, it delivers excellent resistance to vibration, corrosion, and extreme temperatures ranging from -40°C to 125°C.
Featuring a bayonet locking mechanism, the connector enables quick, tool-free mating and unmating, ensuring secure connections even under high mechanical stress. With a rated current of 15A per contact and a rated voltage of 250V AC/DC, it supports stable operation in automation systems, industrial machinery, and outdoor equipment.
Its IP67 ingress protection rating prevents dust and water intrusion, making it ideal for demanding industrial applications where durability and performance are critical.
Technical Data
| Series | HE insert series |
| Connection type | Spring connection (quick connection) |
| Male/female | Male |
| Specifications | 6B |
| Number of connector contacts | 6 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 400/690V 6KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.5-4.0mm² |
| Wire gauge (AWG) | 20-12 AWG |
| Tightening/testing torque | 0.5Nm |
| Stripping length | 9-10mm |
| Standard | DIN EN 60 664, DIN EN 61 984 |
