The HE-006-MC is a high-reliability industrial circular connector, specially designed for secure power and signal transmission in harsh industrial settings. It features a sturdy metal housing that provides superior resistance to vibration, corrosion, and extreme temperatures from -40°C to 125°C, ensuring long-lasting performance in tough conditions.
Equipped with a precision bayonet locking system, it enables tool-free, fast mating and unmating while maintaining a tight, anti-loosening connection even under strong mechanical stress. Rated at 15A per contact and 250V AC/DC, it is well-suited for automation lines, industrial machinery, and outdoor electrical equipment.
Boasting an IP67 ingress protection rating, it effectively blocks dust and water intrusion, making it ideal for mission-critical industrial applications.
Technical Data
| Series | HE insert series |
| Connection type | Crimp connection |
| Male/female | Male |
| Specifications | 6B |
| Number of connector contacts | 6 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 500V |
| Rated pulse voltage | 6KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 16A 400/690V 6KV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated; Gold-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-4.0mm² |
| Wire gauge (AWG) | 26-12 AWG |
| Stripping length | 7.5mm |
| Standard | DIN EN 60 664; DIN EN 61984 |
