The HD-064-MC/P is a high-performance industrial circular connector optimized for harsh working conditions. Built with a lightweight yet durable metal-clad polymer housing, it achieves IP67 ingress protection, effectively shielding against dust, liquid intrusion, and moderate mechanical impact for versatile indoor and outdoor use.
Equipped with gold-plated electrical contacts, this connector ensures stable current and voltage transmission with minimal contact resistance. The corrosion-resistant plating extends service life and maintains reliable connectivity even through frequent mating cycles, making it suitable for continuous operation scenarios.
Integrated with a user-friendly push-pull locking mechanism, the HD-064-MC/P enables tool-free, quick connection and disconnection. Compact, industry-standard compliant, and highly adaptable, it serves as a dependable solution for critical electrical links in automation systems, renewable energy equipment, and vehicle electronics.
Technical Data
| Series | HD insert series |
| Connection type | Crimp connection |
| Male/female | Male |
| Specifications | 24B、48B |
| Number of connector contacts | 64 |
| Grounding contacts | Yes |
| Rated current | 10A |
| Rated voltage | 250V |
| Rated pulse voltage | 4KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 10A 230/400V 4kV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤5mΩ |
| Wire gauge (mm²) | 0.5-1.5mm²、1.5-2.5mm² |
| Wire gauge (AWG) | 20-16 AWG、16-14 AWG |
| Standard | DIN EN 60 664、DIN EN 61984 |
