The HD-040-FC/P is a high-performance industrial circular connector engineered for harsh operating environments. Featuring a durable fiberglass-reinforced polymer housing with IP67 ingress protection, it provides robust resistance to dust, moisture, and chemical corrosion, making it suitable for both indoor and outdoor industrial deployments.
Equipped with precision gold-plated contacts, this connector ensures stable current and voltage transmission with minimal contact resistance. The anti-corrosion plating enhances durability and maintains reliable connectivity even through frequent mating and unmating cycles, catering to continuous operation requirements.
Integrated with a user-friendly push-pull locking mechanism, the HD-040-FC/P enables tool-free, quick connection and disconnection. Compact, compliant with international industry standards, and highly adaptable, it is a trusted solution for critical electrical links in automation equipment, renewable energy systems, and transportation electronics.
Technical Data
| Series | HD insert series |
| Connection Type | Crimp connection |
| Male/Female | Female |
| Specifications | 16B; 32B |
| Number of Connector Contacts | 40 |
| Grounding Contacts | Yes |
| Rated Current | 10A |
| Rated Voltage | 250V |
| Rated Pulse Voltage | 4KV |
| Class of Pollution | 3 |
| Parameters when Class of Pollution is 2 | 10A, 230/400V, 4kV, 2 |
| Rated Voltage as per UL/CSA | 600V |
| Insulation Resistance | ≥10¹⁰Ω |
| Working Temperature | -40℃...+125℃ |
| Mating Cycles | ≥500 |
| Inserts Material | Polycarbonate |
| Inserts Color | RAL 7032 (light gray) |
| Flame Retardant Rating as per UL94 | V0 |
| Contact Material | Copper alloy |
| Surface Treatment | Silver-plated |
| Contact Resistance | ≤5mΩ |
| Wire Gauge (mm²) | 0.5-1.5mm²; 1.5-2.5mm² |
| Wire Gauge (AWG) | 20-16 AWG; 16-14 AWG |
| Standard | DIN EN 60 664; DIN EN 61984 |
