The HD-015-MC is a compact, high-performance industrial circular connector optimized for space-constrained harsh environments. Constructed with a rugged metal housing and rated IP67 for ingress protection, it effectively shields against dust, moisture, and light mechanical impact, making it ideal for dense automation setups and portable industrial devices.
Equipped with high-conductivity gold-plated contacts, this connector ensures stable, low-resistance current and voltage transmission. The corrosion-resistant plating extends service life and maintains reliable connectivity even with frequent mating cycles, suiting applications requiring repeated connection and disconnection.
Integrated with a secure bayonet locking mechanism, the HD-015-MC enables fast, tool-free mating and unmating. Compliant with international industry standards and designed for miniaturized systems, it serves as a dependable solution for critical electrical links in robotics, sensor networks, and compact renewable energy components.
Technical Data
| Series | HD insert series |
| Connection type | Crimp connection |
| Male/female | Male |
| Specifications | 10A |
| Number of connector contacts | 15 |
| Grounding contacts | Yes |
| Rated current | 10A |
| Rated voltage | 250V |
| Rated pulse voltage | 4KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 10A 230/400V 4kV 2 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated、Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Stripping length | 5mm、6mm、8mm |
| Standard | DIN EN 60 664、DIN EN 61984 |
