The HD-008-FC is a compact, high-performance industrial circular connector engineered for space-limited harsh working conditions. Featuring a lightweight fiberglass-reinforced polymer housing with IP67 ingress protection, it offers robust resistance to dust, moisture, and chemical corrosion, ideal for dense instrumentation setups and portable industrial devices.
Equipped with precision gold-plated contacts, this connector ensures stable, low-resistance current and voltage transmission. The anti-corrosion plating enhances durability and maintains reliable connectivity even through frequent mating and unmating cycles, catering to applications requiring repeated connection operations.
Integrated with a user-friendly push-pull locking mechanism, the HD-008-FC enables tool-free, quick connection and disconnection. Compliant with international industry standards and optimized for miniaturized systems, it is a trusted solution for critical electrical links in robotics, sensor networks, and compact renewable energy components.
Technical Data
| Series | HD insert series |
| Connection type | Crimp connection |
| Male/female | Female |
| Specifications | 3A |
| Number of connector contacts | 8 |
| Grounding contacts | No |
| Rated current | 10A |
| Rated voltage | 120V DC、50V AC |
| Rated pulse voltage | 0.8KV |
| Class of pollution | 3 |
| Rated voltage as per UL/CSA | 50V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated、Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Stripping length | 5mm、6mm、8mm |
| Standard | DIN EN 60 664、DIN EN 61984 |
