The HA-016-FC(17-32) industrial connector is a high-performance, high-density component engineered for stable multi-channel signal and power transmission in extreme industrial environments. It features a corrosion-resistant aluminum alloy housing with IP68 ingress protection, effectively withstanding dust, prolonged water immersion, and extreme temperature variations from -60°C to 140°C.
Equipped with 16 premium gold-plated contacts, it delivers ultra-low contact resistance (<8mΩ), complies with IEC 61076-2-101 standards, and supports a rated current of 10A per contact and voltage of 350V AC/DC.
Its advanced cam-lock mechanism enables tool-free, vibration-proof mating in seconds, minimizing installation time and operational interruptions. Compact, durable, and high-efficiency, this connector is ideal for heavy-duty automation systems, marine communication equipment, and high-density outdoor sensor networks.
Technical Data
| Series | HA insert series |
| Connection type | Crimp connection |
| Gender | Female |
| Specifications | 16A, 32A |
| Number of connector contacts | 16 |
| Grounding contacts | Yes |
| Rated current | 16A |
| Rated voltage | 250V |
| Rated pulse voltage | 4KV |
| Class of pollution | 3 |
| Parameters (pollution class 2) | 10A, 230/400V, 4kV, 2 |
| Rated voltage (UL/CSA) | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating (UL94) | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated, Gold-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.14-4.0mm² |
| Wire gauge (AWG) | 26-12 AWG |
| Stripping length | 7.5mm |
| Standard | DIN EN 60 664, DIN EN 61984 |
