The HA-004-MQ industrial connector is a compact, high-efficiency component tailored for reliable signal and power transmission in harsh industrial settings. It features a sturdy die-cast zinc alloy housing with IP67 ingress protection, effectively shielding against dust, splash water, and temperature fluctuations ranging from -40°C to 125°C.
Equipped with 4 gold-plated contacts, it ensures minimal contact resistance (<20mΩ), adheres to IEC 61076-2-101 standards, and supports a rated current of 10A and voltage of 250V AC/DC.
Its twist-lock mechanism enables tool-free, secure mating in seconds, reducing installation time and operational downtime. Robust, cost-effective, and space-saving, this connector is the optimal choice for industrial automation, sensor networks, and outdoor control panels.
Technical Data
| Series | HA insert series |
| Connection Type | Spring connection (quick connection) |
| Male/Female | Male |
| Specifications | 3A |
| Number of Connector Contacts | 4 |
| Grounding Contacts | Yes |
| Rated Current | 10 A |
| Rated Voltage - Phase to Ground | 230 V |
| Rated Voltage - Phase to Phase | 400 V |
| Rated Pulse Voltage | 4 kV |
| Class of Pollution | 3 |
| Parameters when Class of Pollution is 2 | 10A 250V 4kV 3 |
| Rated Voltage as per UL/CSA | 600 V |
| Insulation Resistance | ≥10¹⁰ Ω |
| Working Temperature | -40℃...+125℃ |
| Mating Cycles | ≥500 |
| Inserts Material | Polycarbonate |
| Inserts Color | RAL 7032 (light gray) |
| Flame Retardant Rating as per UL94 | V0 |
| Contact Material | Copper alloy |
| Surface Treatment | Silver-plated |
| Contact Resistance | ≤3 mΩ |
| Wire Gauge (mm²) | 0.5-2.5 mm² |
| Wire Gauge (AWG) | 20-12 AWG |
| Stripping Length | 10±0.5 mm |
| Standard | DIN EN 60 664; DIN EN 61984 |
