The HA-004-M-V2 industrial connector is an upgraded, compact component engineered for reliable signal and power transmission in harsh industrial settings. It features a reinforced die-cast zinc alloy housing with IP67 ingress protection, effectively shielding against dust, splash water, and temperature fluctuations ranging from -45°C to 125°C.
Equipped with 4 enhanced gold-plated contacts, it ensures minimal contact resistance (<15mΩ), complies with IEC 61076-2-101 standards, and supports a rated current of 12A and voltage of 250V AC/DC.
Its optimized twist-lock mechanism enables tool-free, secure mating in seconds, reducing installation time and operational downtime. Lightweight, durable, and cost-effective, this upgraded connector is the optimal choice for light-duty automation, sensor networks, and space-constrained control systems.
Technical Data
| Series | HA insert series |
| Connection type | Screw connection |
| Male/female | Male |
| Specifications | 3A |
| Number of connector contacts | 4 |
| Grounding contacts | Yes |
| Rated current | 10A |
| Rated voltage - phase to ground | 230V |
| Rated voltage - phase to phase | 400V |
| Rated pulse voltage | 4KV |
| Class of pollution | 3 |
| Parameters when class of pollution is 2 | 10A 250V 4kV 3 |
| Rated voltage as per UL/CSA | 600V |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.75-1.5mm² |
| Wire gauge (AWG) | 18-16 AWG |
| Tightening/testing torque | 0.25Nm |
| Stripping length | 2.5-5.5mm |
| Standard | DIN EN 60 664; DIN EN 61984 |
