The H3A-SE/S-2B-M20-RJ45/M Cat.6a is an industrial-grade RJ45 connector designed for reliable high-speed data transmission in harsh environments. Supporting Cat.6a performance, it enables stable 10-Gigabit Ethernet communication with excellent signal integrity and minimal crosstalk, making it suitable for demanding industrial networks.
Featuring a robust heavy-duty housing and an M20 cable gland, this connector provides effective strain relief and secure cable fixation. The shielded RJ45 interface enhances EMC protection, ensuring dependable data transmission even in environments with strong electrical interference, vibration, dust, and moisture.
The H3A-SE/S-2B-M20-RJ45/M Cat.6a is ideal for applications such as industrial automation, control cabinets, transportation systems, and smart manufacturing. Its compact design, easy installation, and high durability make it a reliable solution for modern industrial Ethernet connections requiring both performance and long-term stability.
Technical Data
| Series | Inserts |
| Product Category | H3A RJ45 |
| Number of connector contacts | 8 |
| Transmission Characteristics | Category 6: Up to 500 MHz |
| Standard | ISO/IEC 11801:2002; EN 50173-1 |
| Transmission Rate | 10/100/1000 Mbit/s, 10 Gbit/s |
| Cable termination | Via piercing contacts |
| Shield | 360-degree full shielding contact |
| Working temperature | -25℃ … +85℃ |
| Housing material | Die casting zinc |
| Housing color | RAL 7037 (field gray) |
| Protection rating | IP65 |
| Mating cycles | ≥500 |
