The H3A-001-F is a high-reliability industrial connector engineered for seamless signal and power transmission in harsh operating environments. Constructed with rugged industrial-grade materials, it delivers consistent performance across industrial automation, heavy-duty machinery, and outdoor instrumentation, withstanding extreme temperatures (-40°C to 130°C), vibration, and chemical exposure.
Equipped with IP67 dustproof and waterproof protection, the connector features a secure locking mechanism to prevent accidental disconnection. Its gold-plated contacts minimize signal attenuation and resist corrosion, extending service life and reducing maintenance costs while complying with international industrial standards for hassle-free system integration.
This cost-effective solution excels in mission-critical applications requiring uninterrupted connectivity, making it a trusted choice for demanding industrial scenarios.
Technical Data
| Series | HM modular insert series |
| Module size | Single module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 1 |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Zinc alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤4mΩ |
| Maximum cable diameter | 3-9.5mm |
