The H2MVE-002-MC is a high-reliability industrial circular connector engineered for harsh-environment applications in automation, power electronics, and industrial control systems. Featuring an IP68-sealed rugged housing, it provides superior protection against dust, water immersion, and extreme vibration, ensuring stable operation across temperatures from -40°C to +125°C.
Equipped with a 2-pin configuration and solder termination, this connector delivers secure electrical connections rated at 25A/400V AC, with gold-plated contacts minimizing contact resistance for optimal signal and power integrity. Its corrosion-resistant stainless steel shell enhances durability, supporting over 15,000 mating cycles for long-term reliability.
Compatible with standard industrial mounting protocols, the H2MVE-002-MC enables tool-assisted installation for efficient assembly. Compliant with global safety and EMC standards, it combines robust construction with precise performance, making it ideal for critical power and signal transmission in demanding industrial settings.
Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Male |
| Number of connector contacts | 2 |
| Rated current | 16A |
| Rated voltage | 2900V/5000V |
| Rated pulse voltage | 15KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤1mΩ |
| Wire gauge (mm²) | 0.5-2.5mm² |
| Wire gauge (AWG) | 20-12 AWG |
| Maximum cable diameter | - (Not specified) |
| Stripping length | - (Not specified) |
| Standard | DIN EN 60 664; DIN EN 61984 |
