H2MK300-001-FC is a high-performance industrial component engineered for reliability and efficiency in demanding operational environments. Crafted with premium-grade materials, it boasts exceptional structural integrity, superior corrosion resistance, and excellent wear resistance, ensuring stable performance under harsh conditions involving friction, chemical exposure, or fluctuating temperatures. Featuring precision-machined dimensions and optimized functional design, this component enables seamless integration with existing systems, meeting mainstream industrial application requirements. Suitable for machinery, automation, aerospace, and marine sectors, it delivers consistent performance while minimizing maintenance needs and operational costs. Compliant with strict industry quality standards, it balances durability and practicality, making it a dependable choice for critical operations that demand long-term stability, adaptability, and high operational efficiency.
Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 1 |
| Rated current | 300A |
| Rated voltage | 1000V AC1300V DC |
| Rated pulse voltage | 8KV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤0.3mΩ |
| Wire gauge (mm²) | 70-120mm² |
| Stripping length | 23.5mm |
| Standard | DIN EN 60 664DIN EN 61 984 |
