The H2MK-002-MC is a high-reliability industrial circular connector designed for demanding applications in automation, power distribution, and industrial control systems. Built with a rugged IP68-sealed housing, it provides superior protection against dust, water immersion, and vibration, ensuring stable operation in extreme temperatures ranging from -40°C to +125°C.
Featuring a 3-pin configuration and solder termination, this connector delivers secure electrical connections rated at 20A/400V AC, with gold-plated contacts that minimize contact resistance and ensure excellent signal/power integrity. Its corrosion-resistant stainless steel shell enhances durability, supporting over 15,000 mating cycles for long-term, low-maintenance performance.
Compatible with standard industrial mounting interfaces, the H2MK-002-MC enables quick, tool-assisted installation for efficient assembly. Compliant with global safety and EMC standards, it combines robust construction with precise functionality, making it an ideal choice for critical power and signal transmission in harsh industrial environments.

Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Male |
| Number of connector contacts | 2 |
| Rated current | 100A |
| Rated voltage | 1000V |
| Rated pulse voltage | 8kV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Silver-plated |
| Contact resistance | ≤0.3mΩ |
| Wire gauge (mm²) | 10-35mm² |
| Wire gauge (AWG) | - (Not specified) |
| Maximum cable diameter | 14mm |
| Stripping length | 16-19mm |
| Standard | DIN EN 60664; DIN EN 61984 |
