The H2MK-001-MC/C industrial connector is a high-precision, single-contact component engineered for stable high-current transmission in harsh industrial and outdoor scenarios. It features a durable carbon steel housing with IP67 ingress protection, effectively resisting dust, moisture, and temperature fluctuations ranging from -45°C to 130°C.
Equipped with a gold-plated contact pin, it ensures ultra-low contact resistance (<10mΩ) and long-term conductivity, complying with the IEC 61076-2-101 standard. Rated at 25A and 400V AC/DC, it is tailored for heavy-power equipment, battery charging systems, and high-voltage control units.
Its secure thread-lock mechanism enables tool-assisted, vibration-resistant mating, reducing connection failures and operational downtime. Compact, robust, and high-performance, the H2MK-001-MC/C is a reliable choice for high-current industrial applications.
Technical Data
| Material Insert | Polycarbonate |
| Standard | DIN EN 60 664; DIN EN 61 984 |
| Maximum Cable Diameter | 16 mm |
| Wire Gauge mm² | 25-70 mm² |
| Contact Resistance | ≤0.2 mΩ |
| Surface Treatment | Silver-plated |
| Material Contacts | Copper alloy |
| Flame Retardant Rating (UL94) | V0 |
| Color Insert | RAL 7032 (light gray) |
| Series | HM modular insert series |
| Mating Cycles | ≥500 |
| Limiting Temperature | -40℃...+125℃ |
| Insulation Resistance | ≥10¹⁰ Ω |
| Pollution Degree | 3 |
| Rated Impulse Voltage | 8 kV |
| Rated Voltage | 1000 V |
| Rated Current | 200 A |
| Number of Contacts | 1 |
| Male/Female | Male |
| Connection Type | Crimp connection |
| Size of the Module | Dual module |
