The H2MC-012-FC is a high-performance industrial connector engineered for reliable power and signal transmission in harsh operating environments. Featuring a robust mechanical structure and IP67-rated sealing, it effectively resists dust, moisture, vibration, and extreme temperatures (-40°C to +125°C), ensuring stable operation in industrial automation, robotics, renewable energy systems, and heavy-duty machinery.
With 12 contacts rated for 16A/500V AC/DC, the connector delivers efficient power distribution and precise signal integrity. Its quick-locking mechanism enables tool-free installation, reducing assembly time and maintenance costs. Constructed from corrosion-resistant alloy and flame-retardant materials, it meets UL, IEC, and RoHS standards, guaranteeing long-term durability and safety.
Ideal for demanding industrial applications, the H2MC-012-FC balances performance, reliability, and ease of use, making it a trusted choice for critical connectivity needs.

Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 12 |
| Rated current | 1.5A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8kV |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+125℃ |
| Mating cycles | ≥500 |
| Inserts material | Polycarbonate |
| Inserts color | RAL 7032 (light gray) |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤10mΩ |
| Standard | DIN EN 60664, DIN EN 61984 |
