The EMC-008-MC is a high-reliability 8-pin anti-interference industrial connector, designed for stable signal and power transmission in harsh environments. Crafted from rugged polycarbonate, it excels in industrial automation, power systems, and precision instrumentation, ensuring compatibility with diverse industrial setups.
Operating reliably within -40°C to 125°C, it meets UL 94 V0 flame-retardant standards and resists vibration and chemical corrosion. Equipped with a secure locking mechanism and high-conductivity copper alloy contacts, it delivers 500+ mating cycles and minimal signal loss, while complying with EN 61984, CE, ISO 9001, and ROHS certifications for seamless integration.
This cost-effective solution offers durable, anti-interference connectivity for mission-critical applications, reducing maintenance costs. It’s a trusted choice for industries demanding long-term stability.

Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Male |
| Number of connector contacts | 8+shield |
| Rated current | 5A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8kv |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Insulation materials | Polycarbonate |
| Outer conductor material | Zinc alloy |
| Outer conductor surface | Nickel |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.09-0.52mm² |
| Wire gauge (AWG) | 28-20 AWG |
| Standard | DIN EN 60664, DIN EN 61984 |
