The EMC-008-FC is a high-performance 6-pin anti-interference industrial connector, engineered for stable signal and power transmission. Constructed with rugged polycarbonate, it excels in industrial automation, power systems, and instrumentation, boasting strong compatibility with diverse industrial setups.
Operating reliably within -40°C to 125°C, it meets UL 94 V0 flame-retardant standards and resists vibration and chemical corrosion. Equipped with a secure locking mechanism and copper alloy contacts, it ensures 500+ mating cycles and minimal signal loss. Compliant with EN 61984, CE, ISO 9001, and ROHS, it integrates seamlessly into existing systems.
This cost-effective solution delivers durable, anti-interference connectivity for mission-critical applications, reducing maintenance costs. It’s a trusted choice for industries demanding long-term stability.

Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 8+shield |
| Rated current | 5A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8kv |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Insulation materials | Polycarbonate |
| Outer conductor material | Zinc alloy |
| Outer conductor surface | Nickel |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.09-0.52mm² |
| Wire gauge (AWG) | 28-20 AWG |
| Standard | DIN EN 60664, DIN EN 61984 |
