The EMC - 004 - FC is a high - performance 4 - pin anti - interference industrial connector belonging to the WAIN HM series. Made of rugged polycarbonate, it is well - suited for stable signal and power transmission in tough industrial settings like power systems and industrial automation equipment. It can work steadily within a temperature range of - 40°C to 125°C and meets the UL 94 V0 flame - retardant standard, effectively withstanding harsh conditions such as vibration and chemical erosion.
This connector is equipped with a secure locking structure to avoid unexpected disconnection during operation. Its copper alloy contacts with excellent conductivity ensure minimal contact resistance and reliable transmission, while also enhancing the connector's durability with a mechanical service life of more than 500 mating cycles. It complies with international standards such as EN 61984 and has obtained CE, ISO 9001, and ROHS certifications, enabling seamless integration with various industrial systems.
As a cost - effective and reliable industrial connection solution, it performs exceptionally well in mission - critical power and signal transmission scenarios. It is a trusted choice for industries that demand stable and long - lasting connectivity, effectively reducing later maintenance costs.

Technical Data
| Series | HM modular insert series |
| Module size | Dual module |
| Connection type | Crimp connection |
| Male/female | Female |
| Number of connector contacts | 4+shield |
| Rated current | 10A |
| Rated voltage | 50V |
| Rated pulse voltage | 0.8kv |
| Class of pollution | 3 |
| Insulation resistance | ≥10¹⁰Ω |
| Working temperature | -40℃...+85℃ |
| Mating cycles | ≥500 |
| Insulation materials | Polycarbonate |
| Outer conductor material | Zinc alloy |
| Outer conductor surface | Nickel |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper alloy |
| Surface treatment | Gold-plated |
| Contact resistance | ≤3mΩ |
| Wire gauge (mm²) | 0.14-2.5mm² |
| Wire gauge (AWG) | 26-14 AWG |
| Standard | DIN EN 60664, DIN EN 61984 |
