The H6B-SF-1L/SC-MCV-2PG16 is intended for industrial systems that require two independent cable entries within a compact connector housing. Its dual PG16 side-outlet configuration supports efficient cable separation and organized routing, helping to reduce installation complexity in control and automation equipment. The single locking design provides secure engagement and stable mechanical retention during operation.
The housing is constructed from die-cast aluminum, ensuring high strength and reliability in demanding environments. A powder-coated surface in RAL 7037 field gray enhances resistance to corrosion, abrasion, and external influences. Integrated sealing elements contribute to effective protection of internal components against dust and moisture.
The metal elastic interlocking interface, together with stainless steel and TPR materials, supports long-term durability and operational safety. Commonly used in industrial machinery, electrical cabinets, and automation systems, the H6B-SF-1L/SC-MCV-2PG16 delivers organized cable management, robust enclosure protection, and dependable performance in heavy-duty connector applications.
Technical Data
| Series | Classic regular housing |
| Specifications | 6B |
| Housing type | Sealed lower housing |
| Housing overview | Metal cap |
| Outgoing method | Side outlet |
| Locking type | Single lock |
| Thread | PG16 |
| Housing material | Die-casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Stainless steel + TPR |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40°C to +125°C |
| Protection rating | IP65 |
