The H6B-SF-1L/SC-M20 is a reliable lower housing designed for heavy-duty connector systems used in industrial environments. Based on the classic 6B size, it provides a compact and secure solution for stable electrical connections, making it suitable for machinery, automation equipment, and control cabinets.
The housing is manufactured from durable die-cast aluminum and finished with a high-quality powder coating in RAL 7037 field gray. This surface treatment offers strong resistance to corrosion, mechanical stress, and harsh operating conditions. The single-lock structure ensures easy installation and a secure connection, while the metal elastic interlocking system improves stability during vibration and repeated use.
With integrated NBR sealing and flame-retardant materials rated UL94 V0, the H6B-SF-1L/SC-M20 delivers effective protection against dust, moisture, and heat. The M20 cable entry supports flexible cable management, ensuring long-term reliability and safe performance in demanding industrial applications.
Technical Data
| Series | Classic regular housing |
| Specifications | 6B |
| Housing type | Sealed lower housing |
| Outgoing method | Side outlet |
| Locking type | Single lock |
| Thread | M20 |
| Housing material | Die casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Stainless steel + TPR |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40℃ ~ +125℃ |
| Protection rating | IP65 |
