The H6B-CCT-1L/SC-M20 is a compact heavy-duty connector housing designed for secure and reliable electrical connections in demanding industrial environments. Suitable for surface mounting applications, it provides effective mechanical protection for automation equipment, control panels, and industrial machinery.
Manufactured from high-quality metal material with a durable surface treatment, the housing offers excellent resistance to corrosion, vibration, and mechanical impact. The M20 threaded cable entry ensures secure cable routing and reliable strain relief, while the single-locking structure enables fast installation and stable connection performance during operation.
With effective sealing performance and a wide operating temperature range, the H6B-CCT-1L/SC-M20 performs reliably in harsh conditions involving dust, moisture, and mechanical stress. Its compact design is ideal for space-limited installations, delivering long service life and dependable industrial connectivity for a wide range of applications.
Technical Data
| Series | Classic regular housing |
| Specifications | 6B |
| Housing type | Cable butting (flying lead lower housing) |
| Outgoing method | Top outlet |
| Locking type | Single lock |
| Thread | M20 |
| Housing material | Die casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Stainless steel + TPR |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40℃…+125℃ |
| Protection rating | IP65 |
