The H48B-SF-1L/S-M32 is part of the classic regular housing series, designed to provide reliable protection for industrial electrical systems. Its sealed lower housing and robust metal cap shield internal components from dust, moisture, and mechanical impacts, ensuring stable performance in demanding environments.
Made from die-cast aluminum with a powder-coated RAL 7037 (field gray) finish, the housing offers excellent corrosion resistance and long-lasting durability. Stainless steel components and NBR seals enhance wear and vibration resistance, while the metal elastic interlocking system ensures secure assembly. A single M32 threaded outlet allows flexible cable routing for easy installation.
Rated IP65 and UL94 V0 flame retardant, this housing guarantees safety and reliability in harsh industrial applications. Its combination of strength, versatility, and ease of installation makes it ideal for machinery and wiring systems requiring durable and efficient housing solutions.
Technical Data
| Series | Classic regular housing |
| Specifications | 48B |
| Housing type | Sealed lower housing |
| Outgoing method | Side outlet |
| Locking type | Single lock |
| Thread | M32 |
| Housing material | Die casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Stainless steel |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40℃…+125℃ |
| Protection rating | IP65 |
