The H32B-SF-1L/S-MCV-2M32 is a high-quality classic regular housing engineered for demanding industrial and outdoor applications. Featuring a sealed lower housing with a sturdy metal cap, it provides reliable protection against dust, moisture, and mechanical impacts, ensuring the safety and longevity of internal components. Its bottom outlet with dual M32 threads allows flexible and efficient cable management, while the dual lock system ensures secure and stable assembly during operation.
Constructed from premium die-cast aluminum, the housing delivers superior strength and corrosion resistance. The surface is treated with a powder coating in RAL 7037 (field gray), providing a professional and long-lasting finish. Its metal elastic interlocking connection enhances structural integrity, while stainless steel and TPR components, together with NBR seals, provide excellent flame-retardant performance according to UL94 standards.
Ideal for industrial automation, control panels, and harsh outdoor environments, the H32B-SF-1L/S-MCV-2M32 combines durability, practicality, and safety, offering dependable protection for sensitive equipment.
Technical Data
| Series | Classic regular housing |
| Specifications | 32B |
| Housing type | Sealed lower housing |
| Housing Overview | Metal cap |
| Outgoing method | Side outlet |
| Locking type | Single lock |
| Thread | M32 |
| Housing material | Die casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Stainless steel |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40℃ … +125℃ |
| Protection rating | IP65 |
