H24B-SF-1L/SC-PG21 | High-Quality Rectangular Connectors

The H24B-SF-1L/SC-PG21 is a classic regular rectangular connector housing engineered for reliable industrial connections. With a 24B specification, it features a sealed lower housing and a side cable outlet with a PG21 threaded entry, allowing secure cable fixation and flexible wiring solutions. The single locking mechanism ensures stable mating while facilitating easy assembly and maintenance.

Constructed from high-quality die-casting aluminum, the housing provides strong mechanical protection and long-lasting durability. Its surface is coated with powder in RAL 7037 field gray, offering excellent resistance to corrosion and environmental wear. The metal elastic interlocking system, along with stainless steel and TPR components, ensures consistent and dependable performance in demanding industrial conditions.

Equipped with NBR seals, the H24B-SF-1L/SC-PG21 achieves IP65 protection, safeguarding internal components from dust and water ingress. With a UL94 V0 flame-retardant rating and a wide working temperature range from -40°C to +125°C, it is ideal for industrial automation, electrical installations, and other applications requiring secure and durable connectivity.

Technical Data
