H16B-SF-1L/SC-CV-M25 | High-Quality Rectangular Connectors

The H16B-SF-1L/SC-CV-M25 is designed for industrial connector installations where enhanced protection and controlled cable routing are required. Built in a 16B housing format, it supports secure connector positioning while offering a compact structure suitable for dense equipment layouts. The design emphasizes stability, safety, and reliable performance in demanding industrial environments.

The housing is manufactured from durable die-cast aluminum, providing strong mechanical support and long-term resistance to industrial stress. Its powder-coated RAL 7037 field gray finish enhances durability and corrosion resistance. The integrated CV design offers additional mechanical coverage, helping protect internal connections from external impact. An M25 threaded cable entry supports standard industrial cables and simplifies wiring operations.

A precisely engineered locking interface ensures consistent connector engagement and reliable mating performance. Integrated sealing elements help reduce dust and moisture ingress, contributing to dependable operation over time. The H16B-SF-1L/SC-CV-M25 is well suited for automation systems, machinery control units, and industrial electrical applications requiring compact design and enhanced connector protection.

Technical Data
