The H10B-SFH-4B-MCV-M25 is a heavy-duty connector housing designed for stable and reliable connections in demanding industrial environments. It features a sealed lower housing with a side outlet design, providing effective protection against dust, moisture, and mechanical impact to ensure safe and continuous operation.
Manufactured from high-quality die-cast aluminum, the housing is finished with a durable powder coating in RAL 7037 field gray, offering excellent corrosion resistance and long-term durability. The M25 threaded cable entry, combined with NBR sealing elements, ensures a tight and secure cable connection. The MCV metal cover and metal elastic interlocking system further enhance mechanical strength and vibration resistance.
The H10B-SFH-4B-MCV-M25 is suitable for a wide range of applications including industrial automation, machinery equipment, control panels, and power transmission systems. Its robust structure, reliable sealing performance, and ease of installation make it an ideal solution for heavy-duty connector housing requirements where safety and durability are essential.
Technical Data
| Series | Classic regular housing |
| Specifications | 10B |
| Housing type | Sealed lower housing |
| Housing Overview | Metal cap |
| Outgoing method | Side outlet |
| Locking type | Dual lock |
| Thread | M25 |
| Housing material | Die casting aluminum |
| Housing color | RAL 7037 (field gray) |
| Surface treatment | Powder coating |
| Interlocking method | Metal elastic connection |
| Material | Galvanized iron |
| Seals | NBR |
| Flame retardant rating as per UL94 | V0 |
| Working temperature | -40℃ … +125℃ |
| Protection rating | IP65 |
